# Add your Unity WebGL apps to next.js projects
<a href="https://discord.gg/YHmsekzMV5">
<img src="https://img.shields.io/discord/779074183551385620?logo=discord" alt="chat on Discord">
</a>
[](https://youtu.be/r2suqlHzE3w)
## System Requirements:
- [Node.js 16.8](https://nodejs.org) or later.
- macOS, Windows (including WSL), and Linux are supported.
## Getting Started
In your terminal/git-bash run the following commands
1. In a new directory create a new nextJS project
```bash
npx create-next-app
```
> Accept all the default options and open your next.js project in a code editor
2. Install webgl-nextjs package to your project
> change directory to the root of your new next.js project and run the following command:
```bash
npm i webgl-nextjs
```
3. Create a new ```pages``` directory in your next project -if it wasn't generated-,
in the `pages` directory create a new file `test.js` and copy and paste the following code.
```javascript
//filename: /pages/test.js
import { WebGL } from 'webgl-nextjs'
import React, { useRef } from 'react';
export default function TestMePage() {
const webGLRef = useRef(null);
var buildUrl = "https://storage.googleapis.com/multisync/multisync/app-builds"; //replace with your CDN
let config = {
dataUrl: buildUrl + "/webgl-test-js.data",//replace with your build file name
frameworkUrl: buildUrl + "/webgl-test-js.framework.js",//replace with your build file name
codeUrl: buildUrl + "/webgl-test-js.wasm",//replace with your build file name
loaderUrl: buildUrl + "/webgl-test-js.loader.js",//replace with your build file name
};
return (
<WebGL
ref={webGLRef}
config={config}
onLoaded={()=>console.log('webgl loaded')}
onMessage={()=>console.log('msg received')}
style={{ width: '100%', height: '100%', position: 'relative' }}
/>
)
}
```
4. In your terminal run
```bash
npm run dev
```
You should see this in your browser under http://localhost:3000/test
<img width="1496" alt="Next.js project running unity WebGL app" src="https://github.com/Multi-Sync/webgl-nextjs/assets/24863504/d1ee0b4d-834a-409b-9ce9-5dfc6a112194">
🥳 You just added WebGL game/app to the next project 🥳
## Usage
```javascript
<WebGL
ref={webGLRef} //reference used to send messages to Unity WebGL app
config={config} //config unity loader config
onLoaded={onLoaded}//onLoaded callback function to be called when unity application is loaded
onMessage={onMessage}//onMessage callback function to be called when unity application sends a message to JS layer
style={{ width: '100%', height: '100%', position: 'relative' }}//add your style
/>
```
#### Rendering
- In UnityEditor, In your Build Settings Set your target platform to WebGL.
- Once the project is built locate the following directory ```Build```, your should have 4 files
- ~.wasm.
- ~.data.
- ~.framework.
- ~.loader.
- Host these 4 files remotely or locally and save their absolute addresses to be used in the config.
```javascript
let config = {
dataUrl: "",//replace with your build file name
frameworkUrl: "",//replace with your build file name
codeUrl: "",//replace with your build file name
streamingAssetsUrl: "StreamingAssets",//replace with StreamingAssets path
loaderUrl: "",//replace with your build file name
};
```
#### Loading
- To run any code after the unity webgl app is loaded, utilize the `onLoaded` callback, it gets triggered once the application is loaded.
```javascript
const onLoaded = () => {
console.log(`Loaded`);
};
```
#### Messaging between JS and Unity
<img width="566" alt="Messaging between JS and Unity" src="https://github.com/Multi-Sync/webgl-nextjs/assets/24863504/b20cea38-a97a-4b59-a66e-b565e3264d99">
- In your Unity project, create Plugins folders ```(Assets/Plugins)``` and add protocol.jslib.
##### Assets/Plugins/protocol.jslib
```javascript
mergeInto(LibraryManager.library, {
SendMessageToJS: function(messageType, messageContent) {
// This method can be called from Unity to send messages to JS.
// Convert pointer to string.
var messageTypeStr = UTF8ToString(messageType);
var messageContentStr = UTF8ToString(messageContent);
// Forward the message to your nextjs app or handle it here.
console.log(`Received message of type ${messageTypeStr}: ${messageContentStr}`);
},
SendMessageToUnity: function(messageType, messageContent) {
// This method can be called from JS to send messages to Unity.
// You'll need to implement a corresponding method in your Unity C# script.
SendMessage('HandleJSMessages', 'ReceiveMessage', `${messageType}\n${messageContent}`);
}
});
```
##### Receiving and Sending messages from Unity to NextJS
- In your Unity Project, create a game object called `HandleJSMessages` and the following script to `HandleJSMessages` gameobject.
```csharp
using System.Runtime.InteropServices;
using UnityEngine;
public class HandleJSMessages : MonoBehaviour
{
[System.Obsolete]
private void Awake()
{
if (Application.platform == RuntimePlatform.WebGLPlayer)
{
Debug.Log("HandleJSMessages Activated");//look for this message in the browser to ensure its working, delete before production
DontDestroyOnLoad(this);
}
}
[DllImport("__Internal")]
private static extern void SendMessageToJS(string messageType, string messageContent);
/// <summary>
/// Sends a message from Unity WebGL build to the nextjs app that has webgl-nextjs package
/// </summary>
/// <param name="type">any type you want</param>
/// <param name="content">the content for the message</param>
[System.Obsolete]
public void SendToJS(string type, string content)
{
string message = type + ":" + content;
Application.ExternalCall("SendMessageToJS", message);
}
/// <summary>
/// Receive message from the nextjs app that has webgl-nextjs package
/// </summary>
/// <param name="message"></param>
[System.Obsolete]
public void ReceiveMessage(string message)
{
var parts = message.Split('\n');//type\ncontent
var type = parts[0];
var content = parts[1];
// Handle the message here. This will be called from JS.
Debug.Log($"Received message of type {type}: {content}");//look for this message in the browser to ensure its working, delete before production
//Some Logic ...
switch(type)
{
case "nextjs-request":
SendToJS("unity-response", "Ahmed");//send message to nextjs
break;
default:
Debug.Log($"received unknown type message {type}");
break;
}
}
}
```
##### Receiving and Sending messages from NextJS to Unity
- To Send a message from NextJS to Unity, utilize the reference to the WebGL component.
```webGLRef.current.sendMessage('MyMessageType', 'Hello, Unity!');// customize the type and the content of the message```
- Upon receiving a message from Unity Webgl, you can utilize the onMessage listener
```javascript
const onMessage = (type, content) => {
console.log(`Received message of type ${type}: ${content}`);// you should see in chrome console
switch(type)
{
//logic based on the type
}
};
```
## Full Example
```javascript
//This file is created in a nextjs projet under /pages/testme.js
//Used for testing it should render your unity webgl app
import { WebGL } from 'webgl-nextjs'
import React, { useRef } from 'react';
export default function TestMePage() {
const webGLRef = useRef(null);
var buildUrl = "./Build"; //replace with your CDN
let config = {
id: "unity-container",
dataUrl: buildUrl + "/test-webgl.data",//replace with your build file name
frameworkUrl: buildUrl + "/test-webgl.framework.js",//replace with your build file name
codeUrl: buildUrl + "/test-webgl.wasm",//replace with your build file name
loaderUrl: buildUrl + "/test-webgl.loader.js",//replace with your build file name
};
const onLoaded = () => {
console.log(`UnityWebGL Loaded`);
webGLRef.current.sendMessage('nextjs-request', 'send me your name');
};
const onMessage = (message) => {
console.log('Received message from Unity, message: ' + message);
const type = message.split(':')[0];
const content = message.split(':')[1];
console.log('type: ' + type + ' content: ' + content);
switch (type) {
case "unity-response":
console.log(`name received:${content}`);
break;
}
}
return (
<WebGL
config={config}
onLoaded={onLoaded}
onMessage={onMessage}
style={{ width: '100%', height: '100%', position: 'relative' }}
ref={webGLRef}
/>
)
}
```
## Support:
- Email: contact.io
- Discord: https://discord.gg/YHmsekzMV5
